SKF NJ 2220 ECML eenrijig cilindrisch rollager
Overzicht
NJ-ontwerp; Boringdiameter 100 mm; Buitendiameter 180 mm; Breedte 46 mm; Cilindrische boring; Bewerkte metalen kooi; Co: 380 kN
Kor:450 kN; Referentiesnelheid 4 000 tpm; Gewicht: 5,32 kg.
Achtervoegsel betekenis
ML - Gefreesde messing kooi, venstertype, binnen- of buitenring gecentreerd
EC - Geoptimaliseerd intern ontwerp met meer en/of grotere rollen en met aangepast roleind/flenscontact
specificatie
| Afmetingen en technische gegevens | |
| Lager GEEN. | NJ 2220 ECML cilinderlager met enkele rij |
| Merk | SKF gemaakt in DUITSLAND |
| Belangrijkste afmetingen | 100×180×46mm |
| d | 100 mm |
| D | 180 mm |
| B | 46 mm |
| d1 | ≈127 mm |
| D1 | ≈156,4 mm |
| F | 119 mm |
| r1,2 | min.2,1 mm |
| r3,4 | min.2,1 mm |
| s | maximaal 2,5 mm |
| Da | min.113 mm |
| Da | maximaal 116 mm |
| Db | min.130 mm |
| Da | max.167,5 mm |
| Ra | maximaal 2 mm |
| C | 380 kN |
| C0 | 450 kN |
| Pu | 54 kN |
| Referentiesnelheid | 4 000 tpm |
| Snelheid beperken | 6 700 tpm |
| Gewicht | 5,32 kg |
vergelijkbaar Eenrijig cilinderrollager
| NJ 305 ECML | 25x62x17 |
| NU 305 ECML | 25x62x17 |
| NUP 305 ECML | 25x62x17 |
| NJ 2305 ECP | 25x62x24 |
| NU 2305 HvJ | 25x62x24 |
| NU 2305 ECP | 25x62x24 |
| NUP 2305ECP | 25x62x24 |
| NJ 2305 ECML | 25x62x24 |
| NU 2305 ECML | 25x62x24 |
| NUP 2305 ECML | 25x62x24 |
| NU 1006 | 30x55x13 |
| N 206 ECP | 30x62x16 |
| NU 206 HvJ | 30x62x16 |
| NU 206 ECP | 30x62x16 |
| NU 206 ECPH | 30x62x16 |
| NU 206 ECML | 30x62x16 |
| NJ 206 HvJ | 30x62x16 |
| NJ 206 ECP | 30x62x16 |
| NUP 206 ECP | 30x62x16 |
| NJ 206 ECML | 30x62x16 |
| NUP 206 ECML | 30x62x16 |
| NJ 2206 HvJ | 30x62x20 |
| NJ 2206 ECP | 30x62x20 |
| NJ 2206 ECPH | 30x62x20 |
| NU 2206 HvJ | 30x62x20 |
| NU 2206 ECP | 30x62x20 |
| NU 2206 ECPH | 30x62x20 |
| NUP 2206 ECP | 30x62x20 |
| NU 2206 ECML | 30x62x20 |
| N 306 ECP | 30x72x19 |
| NJ 306 HvJ | 30x72x19 |
| NJ306ECM | 30x72x19 |
| NJ 306 ECP | 30x72x19 |
| NU 306 HvJ | 30x72x19 |
| NU 306ECM | 30x72x19 |
| NU 306 ECP | 30x72x19 |
| NUP 306 HvJ | 30x72x19 |
| NUP 306ECM | 30x72x19 |
| NUP 306ECNJ | 30x72x19 |
| NUP 306ECP | 30x72x19 |
| NJ 306 ECML | 30x72x19 |
| NU 306 ECML | 30x72x19 |
| NUP 306 ECML | 30x72x19 |
| NJ 2306 ECP | 30x72x27 |
| NJ 2306ECPH | 30x72x27 |
| NU 2306 ECP | 30x72x27 |
| NU 2306 ECPH | 30x72x27 |
| NUP 2306ECP | 30x72x27 |
| NJ 2306 ECML | 30x72x27 |
| NU 2306 ECML | 30x72x27 |
| NUP 2306 ECML | 30x72x27 |
| CRL 10 A | 31.75x69.85x17.462 |
| NU 1007 ECP | 35x62x14 |
| NU 1007 ECPH | 35x62x14 |
| N 207 ECM | 35x72x17 |
| N 207 ECP | 35x72x17 |
| NJ 207 HvJ | 35x72x17 |
| NJ 207 ECM | 35x72x17 |
| NJ 207 ECP | 35x72x17 |
| NJ 207 ECPH | 35x72x17 |
| NU 207 HvJ | 35x72x17 |
| NU 207 ECM | 35x72x17 |
| NU 207 ECP | 35x72x17 |
| NU 207 ECPH | 35x72x17 |
| NUP 207 HvJ | 35x72x17 |
| NUP 207 ECM | 35x72x17 |
| NUP 207 ECP | 35x72x17 |
| NJ 207 ECML | 35x72x17 |
| NU 207 ECML | 35x72x17 |
| NUP 207 ECML | 35x72x17 |
| N 2207 ECM | 35x72x23 |
| NJ 2207 HvJ | 35x72x23 |
| NJ 2207 ECP | 35x72x23 |
| NJ 2207 ECPH | 35x72x23 |
| NU 2207 HvJ | 35x72x23 |
| NU 2207 ECP | 35x72x23 |
| NU 2207 ECPH | 35x72x23 |
| NUP 2207ECP | 35x72x23 |
| NJ 2207 ECML | 35x72x23 |
| NU 2207 ECML | 35x72x23 |
| N 307 ECM | 35x80x21 |
| N 307 ECP | 35x80x21 |
| NF 307 ECP | 35x80x21 |
| NJ 307 HvJ | 35x80x21 |
| NJ307ECM | 35x80x21 |
| NJ 307 ECP | 35x80x21 |
| NJ 307 ECPH | 35x80x21 |
| NU 307 HvJ | 35x80x21 |
| NU 307ECM | 35x80x21 |
| NU 307 ECP | 35x80x21 |
| NU 307 ECPH | 35x80x21 |
| NUP 307 HvJ | 35x80x21 |
| NUP 307 ECM | 35x80x21 |
| NUP 307 ECP | 35x80x21 |
| NJ 307 ECML | 35x80x21 |
| NU 307 ECML | 35x80x21 |
| NUP 307 ECML | 35x80x21 |
| NJ 2307 ECP | 35x80x31 |
| NJ 2307 ECPH | 35x80x31 |
| NU 2307 HvJ | 35x80x31 |
| NU 2307 ECP | 35x80x31 |
| NU 2307 ECPH | 35x80x31 |
| NUP 2307 ECP | 35x80x31 |
| NU 1008 ml | 40x68x15 |
| N 208 ECP | 40x80x18 |
| N 208 ECPH | 40x80x18 |
| NJ 208 HvJ | 40x80x18 |
| NJ 208ECM | 40x80x18 |
| NJ 208 ECP | 40x80x18 |
| NJ 208 ECPH | 40x80x18 |
| NU 208 HvJ | 40x80x18 |
| NU 208ECM | 40x80x18 |
| NU 208 ECP | 40x80x18 |
| NU 208 ECPH | 40x80x18 |
| NUP 208 HvJ | 40x80x18 |
| NUP 208 ECM | 40x80x18 |
| NUP 208 ECP | 40x80x18 |
| NJ 208 ECML | 40x80x18 |
| NU 208 ECML | 40x80x18 |
| NUP 208 ECML | 40x80x18 |
| NJ 2208 HvJ | 40x80x23 |
| NJ 2208 ECP | 40x80x23 |
| NJ 2208 ECPH | 40x80x23 |
| NU 2208 HvJ | 40x80x23 |
| NU 2208 ECP | 40x80x23 |
| NU 2208 ECPH | 40x80x23 |
| NUP 2208 HvJ | 40x80x23 |
| NUP 2208ECP | 40x80x23 |
| NJ 2208 ECML | 40x80x23 |
| NU 2208 ECML | 40x80x23 |
| N 308ECM | 40x90x23 |
| N 308 ECP | 40x90x23 |
| NJ 308 HvJ | 40x90x23 |
| NJ308ECM | 40x90x23 |
| NJ 308 ECP | 40x90x23 |
| NJ 308 ECPH | 40x90x23 |
| NU 308 HvJ | 40x90x23 |
| NU 308ECM | 40x90x23 |
| NU 308 ECP | 40x90x23 |
| NU 308 ECPH | 40x90x23 |
| NUP 308ECM | 40x90x23 |
| NUP 308 ECP | 40x90x23 |
| NJ 308 ECML | 40x90x23 |
| NU 308 ECML | 40x90x23 |
| NUP 308 ECML | 40x90x23 |
| NJ 2308 HvJ | 40x90x33 |
| NJ 2308 ECP | 40x90x33 |
| NJ 2308ECPH | 40x90x33 |
| NU 2308 HvJ | 40x90x33 |
| NU 2308 ECP | 40x90x33 |
| NU 2308 ECPH | 40x90x33 |
| NUP 2308 ECM | 40x90x33 |
| NUP 2308 ECP | 40x90x33 |
| NJ 2308 ECML | 40x90x33 |
| NU 2308 ECML | 40x90x33 |
| NUP 2308 ECML | 40x90x33 |
| NJ 1009ECP | 45x75x16 |
| NU 1009 ECP | 45x75x16 |
| NU 1009 ECPH | 45x75x16 |
| NJ 2009 ECP | 45x75x19 |
| N 209 ECP | 45x85x19 |
| NJ 209 HvJ | 45x85x19 |
| NJ 209ECM | 45x85x19 |
| NJ 209 ECP | 45x85x19 |
| NJ 209 ECPH | 45x85x19 |
| NU 209 HvJ | 45x85x19 |
| NU 209 ECM | 45x85x19 |
| NU 209 ECP | 45x85x19 |
| NU 209 ECPH | 45x85x19 |
| NUP 209 HvJ | 45x85x19 |
| NUP 209 ECM | 45x85x19 |
| NUP 209 ECP | 45x85x19 |
| NUP 209 ECPH | 45x85x19 |
| NJ 209 ECML | 45x85x19 |
| NU 209 ECML | 45x85x19 |
| NUP 209 ECML | 45x85x19 |
| NJ 2209 HvJ | 45x85x23 |
| NJ 2209ECNJ | 45x85x23 |
| NJ 2209ECP | 45x85x23 |
| NJ 2209 ECPH | 45x85x23 |
| NU 2209 HvJ | 45x85x23 |
| NU 2209 ECP | 45x85x23 |
| NU 2209 ECPH | 45x85x23 |
| NUP 2209ECP | 45x85x23 |
| NUP 309 ECML | 45x100x25 |
| N 309 ECP | 45x100x25 |
| NJ 309 HvJ | 45x100x25 |
| NJ309ECM | 45x100x25 |
| NJ 309 ECP | 45x100x25 |
| NJ 309 ECPH | 45x100x25 |
| NU 309 HvJ | 45x100x25 |
| NU 309ECM | 45x100x25 |
| NU 309 ECP | 45x100x25 |
| NU 309 ECPH | 45x100x25 |
| NUP 309 HvJ | 45x100x25 |
| NUP 309 ECNP | 45x100x25 |
| NUP 309 ECP | 45x100x25 |
| NJ 309 ECML | 45x100x25 |
| NU 309 ECML | 45x100x25 |
| NJ 2309ECP | 45x100x36 |
| NU 2309 ECP | 45x100x36 |
| NUP 2309 ECP | 45x100x36 |
| NJ 2309 ECML | 45x100x36 |
| NU 2309 ECML | 45x100x36 |
| NUP 2309 ECML | 45x100x36 |
| NU 1010ML | 50x80x16 |
| NU 1010 ECP | 50x80x16 |
| N 210 ECP | 50x90x20 |
| NJ 210 HvJ | 50x90x20 |
| NJ 210ECM | 50x90x20 |
| NJ 210 ECP | 50x90x20 |
| NJ 210 ECPH | 50x90x20 |
| NU 210 HvJ | 50x90x20 |
| NU 210ECM | 50x90x20 |
| NU 210 ECP | 50x90x20 |
| NU 210 ECPH | 50x90x20 |
| NUP 210 HvJ | 50x90x20 |
| NUP 210 ECP | 50x90x20 |
| NJ 210 ECML | 50x90x20 |
| NU 210 ECML | 50x90x20 |
| NUP 210 ECML | 50x90x20 |
| NJ 2210 HvJ | 50x90x23 |
| NJ 2210 ECP | 50x90x23 |
| NJ 2210ECPH | 50x90x23 |
| NU 2210 HvJ | 50x90x23 |
| NU 2210ECM | 50x90x23 |
| NU 2210 ECP | 50x90x23 |
| NU 2210 ECPH | 50x90x23 |
| NUP 2210 HvJ | 50x90x23 |
| NUP 2210 ECNP | 50x90x23 |
| NUP 2210 ECP | 50x90x23 |
| NJ 2210 ECML | 50x90x23 |
| NU 2210 ECML | 50x90x23 |
| NUP 2210 ECML | 50x90x23 |
| N 310 ECP | 50x110x27 |
| NJ 310 HvJ | 50x110x27 |
| NJ310ECM | 50x110x27 |
| NJ 310 ECP | 50x110x27 |
| NJ 310 ECPH | 50x110x27 |
| NU 310 HvJ | 50x110x27 |
| NU 310ECM | 50x110x27 |
| NU 310 ECP | 50x110x27 |
| NU 310 ECPH | 50x110x27 |
| NUP 310 HvJ | 50x110x27 |
| NUP 310ECP | 50x110x27 |
| NJ 310 ECML | 50x110x27 |
| NU 310 ECML | 50x110x27 |
| NUP 310 ECML | 50x110x27 |
| NJ 2310 ECP | 50x110x40 |
| NJ 2310ECPH | 50x110x40 |
| NU 2310 ECP | 50x110x40 |
| NU 2310 ECPH | 50x110x40 |
| NUP 2310 ECP | 50x110x40 |
| NJ 2310 ECML | 50x110x40 |
| NU 2310 ECML | 50x110x40 |
| NUP 2310 ECML | 50x110x40 |
| NJ 1011 ECP | 55x90x18 |
| NU 1011 ECP | 55x90x18 |
| N 211 ECP | 55x100x21 |
| NJ 211 HvJ | 55x100x21 |
| NJ 211ECM | 55x100x21 |
| NJ 211 ECP | 55x100x21 |
| NJ 211 ECPH | 55x100x21 |
| NU 211 HvJ | 55x100x21 |
| NU 211ECM | 55x100x21 |
| NU 211 ECP | 55x100x21 |
| NU 211 ECPH | 55x100x21 |
| NUP 211 HvJ | 55x100x21 |
| NUP 211ECM | 55x100x21 |
| NUP 211 ECP | 55x100x21 |
| NJ 211 ECML | 55x100x21 |
| NU 211 ECML | 55x100x21 |
| NUP 211 ECML | 55x100x21 |
| NJ 2211 HvJ | 55x100x25 |
| NJ 2211ECM | 55x100x25 |
| NJ 2211 ECP | 55x100x25 |
| NJ 2211ECPH | 55x100x25 |
| NU 2211 HvJ | 55x100x25 |
| NU 2211 ECP | 55x100x25 |
| NU 2211 ECPH | 55x100x25 |
| NUP 2211ECP | 55x100x25 |
| NUP 2211 ECPH | 55x100x25 |
| NJ 2211 ECML | 55x100x25 |
| NU 2211 ECML | 55x100x25 |
| NUP 2211 ECML | 55x100x25 |
| N 311ECM | 55x120x29 |
| N 311 ECP | 55x120x29 |
| NJ 311 HvJ | 55x120x29 |
| NJ 311ECM | 55x120x29 |
| NJ 311 ECP | 55x120x29 |
| NU 311 HvJ | 55x120x29 |
| NU 311ECM | 55x120x29 |
| NU 311 ECP | 55x120x29 |
| NUP 311 HvJ | 55x120x29 |
| NUP 311ECM | 55x120x29 |
| NUP 311 ECP | 55x120x29 |
| NJ 311 ECML | 55x120x29 |
| NU 311 ECML | 55x120x29 |
| NUP 311 ECML | 55x120x29 |
| NJ 2311 ECP | 55x120x43 |
| NJ 2311ECPH | 55x120x43 |
| NU 2311 ECP | 55x120x43 |
| NU 2311 ECPH | 55x120x43 |
| NUP 2311 ECP | 55x120x43 |
| NJ 2311 ECML | 55x120x43 |
| NU 2311 ECML | 55x120x43 |
| NUP 2311 ECML | 55x120x43 |
| CRM18A | 57.15x127x31.75 |
| NU 1012ML | 60x95x18 |
| NU 1012 ECP | 60x95x18 |
| N 212 ECM | 60x110x22 |
| N 212 ECP | 60x110x22 |
| NJ 212 HvJ | 60x110x22 |
| NJ 212ECM | 60x110x22 |
| NJ 212 ECP | 60x110x22 |
| NU 212 HvJ | 60x110x22 |
| NU 212 ECM | 60x110x22 |
| NU 212 ECP | 60x110x22 |
| NUP 212 HvJ | 60x110x22 |
| NUP 212 ECM | 60x110x22 |
| NUP 212 ECP | 60x110x22 |
| NJ 212 ECML | 60x110x22 |
| NU 212 ECML | 60x110x22 |
| NUP 212 ECML | 60x110x22 |
| NJ 2212 HvJ | 60x110x28 |
| NJ 2212 ECM | 60x110x28 |
| NJ 2212 ECP | 60x110x28 |
| NJ 2212 ECPH | 60x110x28 |
| NU 2212 HvJ | 60x110x28 |
| NU 2212 ECM | 60x110x28 |
| NU 2212 ECP | 60x110x28 |
| NU 2212 ECPH | 60x110x28 |
| NUP 2212 HvJ | 60x110x28 |
| NUP 2212 ECM | 60x110x28 |
| NUP 2212 ECP | 60x110x28 |
| NJ 2212 ECML | 60x110x28 |
| NU 2212 ECML | 60x110x28 |
| NUP 2212 ECML | 60x110x28 |
| N 312 HvJ | 60x130x31 |
| N 312ECM | 60x130x31 |
| N 312 ECP | 60x130x31 |
| NJ 312 HvJ | 60x130x31 |
| NJ312ECM | 60x130x31 |
| NJ 312 ECP | 60x130x31 |
| NJ 312 ECPH | 60x130x31 |
| NU 312 HvJ | 60x130x31 |
| NU 312ECM | 60x130x31 |
| NU 312 ECP | 60x130x31 |
| NU 312 ECPH | 60x130x31 |
| NUP 312 HvJ | 60x130x31 |
| NUP 312 ECM | 60x130x31 |
| NUP 312 ECP | 60x130x31 |
| NJ 312 ECML | 60x130x31 |
| NU 312 ECML | 60x130x31 |
| NUP 312 ECML | 60x130x31 |
| NJ 2312 ECM | 60x130x46 |
| NJ 2312 ECP | 60x130x46 |
| NJ 2312 ECPH | 60x130x46 |
| NU 2312 ECM | 60x130x46 |
| NU 2312 ECP | 60x130x46 |
| NU 2312 ECPH | 60x130x46 |
| NUP 2312ECP | 60x130x46 |
| NJ 2312 ECML | 60x130x46 |
| NU 2312 ECML | 60x130x46 |
| NUP 2312 ECML | 60x130x46 |
| CRM20 A | 63.5x139.7x31.75 |
| NU 1013 ml | 65x100x18 |
| NU 1013ECP | 65x100x18 |
| NU 1013 ECPH | 65x100x18 |
| N 213 ECP | 65x120x23 |
| NJ 213 HvJ | 65x120x23 |
| NJ 213ECM | 65x120x23 |
| NJ 213 ECP | 65x120x23 |
| NU 213 HvJ | 65x120x23 |
| NU 213ECM | 65x120x23 |
| NU 213ECP | 65x120x23 |
| NUP 213 HvJ | 65x120x23 |
| NUP 213 ECP | 65x120x23 |
| NJ 213 ECML | 65x120x23 |
| NU 213 ECML | 65x120x23 |
| NUP 213 ECML | 65x120x23 |
| NUB 213 HvJ | 65x120x31 |
| NJ 2213 HvJ | 65x120x31 |
| NJ 2213 ECP | 65x120x31 |
| NU 2213 HvJ | 65x120x31 |
| NU 2213 ECP | 65x120x31 |
| NUP 2213ECP | 65x120x31 |
| NJ 2213 ECML | 65x120x31 |
| NU 2213 ECML | 65x120x31 |
| N 313ECM | 65x140x33 |
| N 313 ECP | 65x140x33 |
| NJ 313 HvJ | 65x140x33 |
| NJ 313ECM | 65x140x33 |
| NJ 313 ECP | 65x140x33 |
| NJ 313 ECPH | 65x140x33 |
| NU 313 HvJ | 65x140x33 |
| NU 313ECM | 65x140x33 |
| NU 313 ECP | 65x140x33 |
| NU 313 ECPH | 65x140x33 |
| NUP 313 HvJ | 65x140x33 |
| NUP 313 ECP | 65x140x33 |
| NJ 313 ECML | 65x140x33 |
| NU 313 ECML | 65x140x33 |
| NUP 313 ECML | 65x140x33 |
| NJ 2313 ECP | 65x140x48 |
| NJ 2313ECPH | 65x140x48 |
| NU 2313 ECP | 65x140x48 |
| NU 2313 ECPH | 65x140x48 |
| NUP 2313 ECP | 65x140x48 |
| NJ 2313 ECML | 65x140x48 |
echte lager foto
Populaire tags: SKF nj 2220 ecml enkele rij cilinderlager, leveranciers, agentschap, prijs, te koop
