29468E - Stuwkrachtlagers met sferische rol
E :hoge belasting cilindrisch rollager,kooi type:Stalen of standaard kooi,
Boordiameter: 340 mm; buitendiameter: 620 mm: dikte 170 mm, gewicht: 220 kg.
Sollicitatie:voornamelijk usd voor assen van spoorwegvoertuigen, lagerhuizen van walserijen, walsrollen, brekers, trilzeven, drukmachines, houtbewerkingsmachines, diverse industriële verloopstukken, verticale zelfinstellende lagers.
| Specificaties | |
| Lager nummer: | 29468E |
| Maat (mm) : | 340*620*170mm |
| Boring diameter | 340 mm |
| Buitendiameter (mm): | 620mm |
| Breedte (mm) : | 170mm |
| r1,2 | minimaal 7,5 mm |
| Basis dynamisch draagvermogen | 6 700 kN |
| Basis statische belastingsclassificatie | 22 400 kN |
| Vermoeidheid belasting limiet | 1 760 kN |
| Referentie snelheid | 560 omw/min |
| Snelheid beperken | 1 000 omw/min |
| Gewicht | 220 kg |
| Tolerantie klasse | Normaal |
| Lager Nr. | Grootte (mm) | Massa (kg) |
| 24122 | 110x180x69 | 6.7 |
| 22222 | 110x200x53 | 7.2 |
| 23222 | 110x200x69.8 | 9.6 |
| 22322 | 110x240x80 | 17.8 |
| 23322 | 110x240x92.1 | 20.4 |
| 23024 | 120x180x46 | 4 |
| 24024 | 120x180x60 | 5.2 |
| 23124 | 120x200x62 | 7.9 |
| 24124 | 120x200x80 | 10 |
| 22224 | 120x215x58 | 9 |
| 23224 | 120x215x76 | 11.8 |
| 22324 | 120x260x86 | 21.4 |
| 23324 | 120x260x106 | 27.8 |
| 23926 | 130x180x37 | 2.8 |
| 23026 | 130x200x52 | 5.9 |
| 24026 | 130x200x69 | 7.8 |
| 23126 | 130x210x64 | 8.6 |
| 24126 | 130x210x80 | 10.5 |
| 22226 | 130x230x64 | 11.3 |
| 23226 | 130x230x80 | 14 |
| 22326 | 130x280x93 | 26.7 |
| 23326 | 130x280x112 | 33.8 |
| 23928 | 140x190x37 | 2.9 |
| 23028 | 140x210x53 | 6.2 |
| 24028 | 140x210x69 | 8.2 |
| 23128 | 140x225x68 | 10.4 |
| 24128 | 140x225x85 | 12.7 |
| 26228 | 140x240x80 | 14.7 |
| 22228 | 140x250x68 | 14.2 |
| 23228 | 140x250x88 | 18 |
| 22328 | 140x300x102 | 33.6 |
| 23328 | 140x300x118 | 41.7 |
| 23030 | 150x225x56 | 7.5 |
| 24030 | 150x225x75 | 10.2 |
| 23130 | 150x250x80 | 15.5 |
| 24130 | 150x250x100 | 19.4 |
| 22230 | 150x270x73 | 17.5 |
| 23230 | 150x270x96 | 23 |
| 22330 | 150x320x108 | 40.6 |
| 23330 | 150x320x128 | 50.4 |
| 23932 | 160x220x45 | 4.9 |
| 23032 | 160x240x60 | 9.3 |
